Features & Benefits
The feature images used on this page are examples to demonstrate the product benefits and may differ slightly from the actual product.
CPV3-486GD-L
48" Series 9
6 Burner with Griddle Gas Rangetop
LPG
- Professional
A powerful six burner rangetop with Professional styling and the additional cooking flexibility of a stainless steel griddle.
Stainless Steel,
LPG
- Finish
- Stainless Steel
- Fuel Type
- LPG
MSRP
$ 8,499.00
48" Series 9
6 Burner with Griddle Gas Rangetop
LPG
- Griddle with burners that deliver up to 19,000 BTU heat per burner, for seriously fast boiling
- Continuous surface grates designed for pots and pans to move safely across the cooktop
- The stainless steel griddle is great for cooking anything from grilled cheese to quesadillas
- Made from quality materials and real stainless steel
LPG gas; requires external gas bottles
Height
8516 "
Width
4778 "
Depth
28 "
PERFECT RESULTS
Cooktop Power
Sealed Dual Flow Burners™ deliver rangetop power up to 19,000 BTU for seriously fast boiling right down to a precise 140°F full surface simmer with the gentlest of flames.
PERFECT RESULTS
Precise Control
From the highest to the lowest temperatures you get total control with halo-illuminated rangetop dials. A precise full surface simmer is delivered across all burners.
BEAUTIFUL TO USE
Cooking Flexibility
The continuous surface grates are designed for pots and pans to move safely across the rangetop. The deep-platform style grates provide full coverage so heat goes directly onto the pot, for a faster boil.
BEAUTIFUL TO USE
Easy To Clean
These rangetops are easy to clean with sealed burners and a continuous, porcelain basepan.
BEAUTIFUL TO USE
Information At A Glance
LED halo control dials provide information at a glance and assist in alerting you if any burners are accidentally left on.
BUILT TO LAST
Design Quality
This rangetop is built to last with craftsmanship in every detail, featuring real stainless steel, cast-iron trivets, and titanium coated dials.
Specifications
- Height
- 8516 "
- Width
- 4778 "
- Depth
- 28 "
Burner ratings
| Burner ratings Attributes | Value |
|---|---|
| Power back centre | 13000BTU |
| Power back left | 13000BTU |
| Power back right | 13000BTU |
| Power front centre | 15000BTU |
| Power front left | 19000BTU |
| Power front right | 15000BTU |
| Power griddle | 15000BTU |
| Total cooktop power | 103000BTU |
Burners
| Burners Attributes | Value |
|---|---|
| Number of burners | 6 |
Cleaning
| Cleaning Attributes | Value |
|---|---|
| Easy clean porcelain basepan |
Controls
| Controls Attributes | Value |
|---|---|
| Metal illuminated dials | |
| Star K Certification |
Gas Requirements
| Gas Requirements Attributes | Value |
|---|---|
| Fitting and pipe | ½ NPT, min. ⅝" ∅ flex line |
| Supply Pressure (LPG) | 11" to 14" W.C |
Performance
| Performance Attributes | Value |
|---|---|
| Auto re-ignition system | |
| Sealed Dual Flow Burners™ | 6 |
| Sealed range top | |
| Simmer on all burners | 140°F |
Power requirements
| Power requirements Attributes | Value |
|---|---|
| Supply frequency | 60Hz |
| Supply voltage | 120V |
Product dimensions
| Product dimensions Attributes | Value |
|---|---|
| Depth | 28" |
| Height | 8 516" |
| Width | 47 78" |
Recommended Back Guards Ventilation
| Recommended Back Guards Ventilation Attributes | Value |
|---|---|
| Combustible situation | BGCV2-3048H |
| Non combustible situation | BGCV2-3048 / BGCV2-1248 |
| Pro hood | HCB48-12_N |
Safety
| Safety Attributes | Value |
|---|---|
| ADA compliant |
Zones
| Zones Attributes | Value |
|---|---|
| Number of elements | 6 |
